The core advantage of this product is its ultra-high test accuracy, with a display accuracy of ±0.2%FS, which can meet the requirements of high-precision motor efficiency detection. It is equipped with a professional temperature rise test system, which can automatically collect the temperature data of motor windings and bearings during the test, and calculate the temperature rise rate in real time. The built-in cloud data synchronization function can upload test data to the enterprise cloud platform, realizing remote data viewing and management. It supports docking with professional motor performance analysis software, which can conduct in-depth analysis of motor performance parameters and provide optimization suggestions for motor design. At the same time, it complies with IEC 60034-2-1 and GB 18613 standards, and the test results have authoritative recognition.
The adaptable motor power range is 1.5kW-500kW, with a rated voltage of AC380V±5% 50/60Hz. The test items include no-load loss test, load efficiency test (range 0-100% efficiency, accuracy ±0.2%), temperature rise test (temperature measurement range 0-150℃, accuracy ±0.5℃) and motor efficiency rating. The overall dimensions are 2200mm (length) * 1500mm (width) * 1800mm (height), with a total weight of 1800kg. It is equipped with a 21.5-inch industrial touch screen, with a data storage capacity of 50,000 test records. The protection grade is IP21, and it supports Ethernet and RS485 communication interfaces for docking with enterprise MES systems. The whole machine adopts a welded structural design, with strong stability and low vibration during testing.
It is suitable for motor energy efficiency testing institutions, large motor production enterprises, quality supervision departments and other scenarios that require high-precision motor performance testing. Typical application cases include energy efficiency rating testing of new energy vehicle motor matching motors, performance verification of high-efficiency fan motors, and spot checks of motor energy efficiency products by market supervision departments. It can help enterprises obtain national energy efficiency certification, improve product market competitiveness, and meet the requirements of national energy conservation and emission reduction policies.
