The key technical advantages include the QR code recognition system that can automatically match test parameters according to motor model information, eliminating manual parameter setting errors. The PLC control system supports fully automatic completion of no-load test, load test, durability test and insulation resistance test within the set test flow. The quick-change motor clamp enables the replacement of tested motors within 3 minutes, improving production line testing efficiency by over 60%. The data cloud platform supports remote access to test data, realizing centralized management of test records across multiple production lines, and providing data support for production quality improvement. It also has multiple safety protection functions such as over-temperature protection, over-current protection and emergency stop.
The test voltage range is 0~1140V AC with ±0.2% FS accuracy, and the test current range is 0~1000A with ±0.1% FS accuracy. The maximum test power is 500kW, and the speed regulation range is 0~5000rpm. The overall dimensions are 2000mm in length, 1500mm in width and 1200mm in height, with a net weight of 320kg. It uses 380V 3-phase 50/60Hz power supply, and supports real-time data acquisition at 20Hz sampling frequency. The quick-change motor clamp is compatible with motor shaft diameters from 20mm to 150mm, and the automatic test flow can be customized according to user needs.
This product is suitable for large-scale motor manufacturing enterprises, automotive motor production lines and new energy industry motor testing workshops. It can be used for full-process testing of mass-produced low voltage motors, including incoming material inspection, production process testing and factory final inspection. It meets the testing requirements of high-power low voltage motors above 100kW, and is suitable for automated production lines with high testing efficiency requirements.
