Basic Low Voltage Motor Test Bench

Product features:

Compared with traditional test equipment, this product adopts a modular design, and the core testing unit can be quickly replaced to adapt to different power motors, reducing subsequent maintenance costs. It is equipped with high-precision sensors and an intelligent calibration system, which does not require frequent manual calibration to maintain a test accuracy of ±0.5%FS. The built-in one-click testing process allows operators to operate independently after only 30 minutes of training, greatly reducing employment thresholds. It supports one-click export of test data in CSV format, facilitating enterprises to conduct quality traceability and report generation. At the same time, it is equipped with RS485 and USB interfaces, which can connect to the existing MES system of the factory, realizing interconnection of production data and solving the industry pain point of data islands in traditional testing equipment.

Product specifications:

The adaptable motor power range is 0.75kW-315kW, with a rated voltage of AC380V±10% 50Hz. The test items include stator insulation resistance test (range 0-1000MΩ, accuracy ±2%), turn-to-turn voltage withstand test (0-5000V, accuracy ±1%), no-load current and voltage test, and locked-rotor torque test. The equipment has an overall dimensions of 1800mm (length) * 1200mm (width) * 1700mm (height), with a total weight of 1200kg. It is equipped with a 15-inch industrial touch screen, with a data storage capacity of 10,000 test records. The protection grade is IP20, and the operation mode supports touch screen operation and physical button assistance. The overall shell is made of cold-rolled steel plate with plastic spraying, which is corrosion-resistant and easy to clean.

Product application:

It is suitable for factory inspection links of small and medium-sized motor manufacturers, motor performance verification of motor maintenance stores, and equipment入库 quality inspection of motor leasing companies. Typical application cases include batch inspection of water pump motors, factory quality control of household fan motors, and performance re-inspection of supporting motors for small construction machinery. It can help enterprises increase the defective product detection rate to more than 99.5%, reduce after-sales repair costs, and meet the test data traceability requirements of the ISO9001 quality system.
