Gantry-Type Large-Scale Metallographic Cutter

Product features:

This large-scale metallographic cutter has the core advantage of being able to process oversized samples, solving the problem that ordinary metallographic cutters cannot cut large-size components. The gantry structural design effectively reduces the deformation of the body during cutting, ensuring a cutting accuracy of ±0.1mm. The pneumatic multi-point clamping system can evenly fix large samples, avoiding sample offset and deformation during cutting. The large-flow water cooling system can quickly reduce the temperature of the blade and sample, preventing tissue changes caused by overheating. It is equipped with a semi-automatic feeding system, which reduces the operating strength of operators and improves cutting efficiency. It also meets international safety certification standards, with multiple safety protection devices to ensure the safety of operators during use.

Product specifications:

Detailed product specifications include: Max Cutting Diameter 300mm, Max Cutting Thickness 200mm, Motor Power 3kW, Rated Rotating Speed 1800r/min, Blade Size Φ500×3.0×50mm, Clamping Range 50-300mm, Power Supply 380V 50Hz, Overall Dimension 2500mm (Length) × 1800mm (Width) × 1600mm (Height), Net Weight 850kg, Cutting Accuracy ±0.1mm, Operation Mode Semi-Automatic Control, Cooling Method Large Flow Water Cooling + Dust Removal, Safety Standards CE Certified. The blade lift distance can reach 150mm, making it easy to replace the cutting blade and adjust the cutting position.

Product application:

This gantry-type large-scale metallographic cutter is mainly applicable to metallographic sample preparation in heavy machinery manufacturing, shipbuilding, aerospace and large-scale metal processing enterprises. It can cut large-size metal castings, steel plates, aluminum alloy profiles, composite materials and other industrial components, providing standard samples for subsequent material performance testing, quality control and failure analysis. It is an ideal equipment for large-scale sample preparation in industrial production and scientific research institutions.
