Adopts fully automated detection mode, which can complete the roundness detection of workpieces at a speed of 100 pieces per hour, greatly improving the production line detection efficiency. It supports real-time data upload to the enterprise MES system, which can realize real-time monitoring of production line quality data and timely early warning of unqualified products. It has a protection level of IP65, which can adapt to the harsh working environment of the production line. It supports multi-station switching, which can meet the detection needs of different types of workpieces on the same production line.
The testing machine has a measurement range of shaft diameter φ10-300mm, with a rotation accuracy of 0.15μm and detection accuracy of ±0.03μm. The detection speed is 100 pieces per hour, and it supports multi-station switching to adapt to different workpiece specifications. It is powered by AC220V 50Hz, and outputs detection data via Modbus TCP interface to facilitate docking with the enterprise's production management system. The overall dimensions are 600mm in length, 500mm in width and 1000mm in height, with a total weight of 350kg. It can be directly integrated into the existing automated production line without occupying too much space.
This product is mainly applicable to the real-time online roundness detection of mass-produced parts in automotive bearing manufacturing, hardware stamping processing, electronic component assembly and other industries. Typical usage scenarios include online detection of automotive bearing inner and outer rings, batch detection of hardware stamping circular parts, and online quality control of electronic device shell production lines, realizing 100% full inspection of production line workpieces and reducing the rate of defective products.
