The core advantage is its super load-bearing capacity and high-power cutting performance. The hydraulic feeding system can provide a maximum clamping force of 5000N, which can firmly fix large specimens with a weight of more than 500kg. The large-flow circulating cooling system can circulate 20L of cooling water per minute, effectively reducing the temperature of the cutting area and preventing the sample from being burned. The IP54 protection grade can meet the dusty and splash environment of heavy industrial workshops, and the anti-vibration base design reduces the vibration generated during cutting, improving the cutting accuracy. It solves the pain point that ordinary cutting machines cannot cut large and thick specimens.
The overall dimensions are 2800mm × 2200mm × 2000mm, the maximum cutting thickness is 300mm, the clamping stroke is 0-500mm, the rated voltage is 380V 50/60Hz, the noise during operation is less than 85dB, and the cutting disc is made of high-strength diamond sintered material with a thickness of 4.5mm. It is equipped with a remote control operation function, which can adjust the parameters remotely in the workshop to avoid the influence of workshop noise and dust on operators.
It is mainly used in heavy industry testing centers, large steel enterprises, engineering machinery manufacturing plants, wind power equipment manufacturing and aerospace heavy material testing. Typical application scenarios include cutting large steel castings, thick steel plates for bridge construction, wind power tower cylinder samples and heavy engineering machinery parts.
