The biggest feature of this portable tester is its strong portability and environmental adaptability. With a weight of only 12kg, it can be easily carried to different on-site working environments. It adopts IP65 dustproof and waterproof design, which can be used in outdoor construction sites and harsh industrial environments. Equipped with a rechargeable lithium battery, it can work continuously for 8 hours without being connected to a fixed power supply. It supports Bluetooth 5.0 wireless transmission, which can synchronize measurement data to mobile phones or tablets in real time, and the supporting mobile app can realize remote operation and data viewing. The simplified operation interface allows even non-professional inspectors to quickly master the use method.
This portable roundness tester has a measuring range of φ20mm to φ300mm, with a resolution of 0.1μm and measurement accuracy of ≤0.1μm. It can bear a maximum workpiece weight of 20kg, suitable for most medium-sized on-site workpieces. The built-in 20000mAh rechargeable lithium battery can support 8 hours of continuous working time, and can be fully charged within 3 hours via the DC adapter. It is equipped with a 7-inch LCD screen, which can clearly display measurement data and analysis results. It supports Bluetooth 5.0 wireless transmission and Type-C data interface, and is compatible with iOS and Android mobile apps to realize mobile data management and remote control. The overall size is 380*280*220mm, which is convenient for storage and transportation.
This portable on-site roundness tester is mainly used for on-site quality inspection in heavy machinery, wind power generation, shipbuilding and other industries. It is suitable for detecting the roundness of wind power generator bearings, large ship shaft parts, heavy engineering machinery transmission shafts and other large components. It can also be used for maintenance and inspection of large mechanical equipment, helping on-site maintenance personnel quickly judge the wear status of parts and avoid unexpected downtime. In addition, it can also be used for mobile quality inspection services provided by third-party metrology institutions.
