Equipped with 8 sets of 12MP industrial cameras for full-coverage PCB detection, the device supports recognition of 200+ common PCB defects including short circuit, open circuit, virtual soldering, bridge soldering, component offset and missing parts. The built-in AI-based SPC analysis system generates real-time production data reports, which can be connected to MES systems for full production data synchronization. Its dust-proof and shock-proof body design adapts to harsh factory workshop environments, and it supports one-click switching of detection templates for different PCB sizes, enabling flexible deployment in various SMT production lines.
Product specifications:
The overall machine dimensions are 2200mm(L)*1500mm(W)*1800mm(H), with an operating weight of 850kg. It supports PCB substrate sizes from 50*50mm to 510*510mm, with a detection accuracy of ±0.01mm and a maximum detection speed of 120cm²/s. The device runs on 220V AC 50/60Hz power, with a working environment requirement of 18-28℃ temperature and 45-75% relative humidity without condensation. It supports Ethernet and USB 3.0 data transmission, uses Windows 10 professional operating system, offers multilingual operation interfaces, and can store over 10,000 historical inspection reports.
It is primarily used for post-SMT patch PCB appearance inspection, covering defects such as circuit short/open circuits, virtual/bridge soldering, component offset/missing and nameplate printing errors. It applies to consumer electronics, automotive electronics and industrial control PCB manufacturing industries, and can be integrated into automated production lines for online full inspection, or used as an offline inspection device for laboratory sampling and batch quality verification.
