It adopts 4K high-definition industrial cameras paired with ring shadowless LED lights to eliminate reflection and shadows, and is equipped with a self-developed AI defect recognition algorithm that supports automatic classification of 12 common defects including scratches, color differences, deformation, and missing materials. It supports one-click rapid changeover, comes with a built-in data statistics report function that can export quality inspection data for production traceability, and has an aluminum alloy frame for stable and durable use. It occupies only 0.2 square meters, making it ideal for small workstations, and can be easily integrated with existing small-scale production lines.
The inspection accuracy reaches ±0.01mm, supporting the detection of tiny defects that are difficult to spot with the naked eye. The maximum detectable workpiece size is 150mm×100mm×50mm, with a detection speed of up to 30 pieces per minute. It is equipped with two 4K 30fps industrial cameras, and the light source can be adjusted between 3000K and 6500K to adapt to different workpiece surface properties. It runs on the Windows 10 embedded operating system, with a 512GB solid-state drive for storing mass quality inspection data, and supports USB 3.0 and Ethernet communication interfaces for data transmission and remote control. The rated power consumption is 150W, with an IP20 protection grade, and the device dimensions are 450mm×350mm×280mm with a net weight of 18kg.
It is suitable for industries such as consumer electronics OEM, electronic component manufacturing, and precision hardware processing. Typical application scenarios include factory quality inspection of mobile phone parts, solder joint detection on PCB boards, appearance sampling inspection of micro fasteners, and defect排查 of small injection molded parts. It can be deployed at the end of production lines, independent quality inspection stations, or small laboratories, and supports transformation and docking with existing production lines to improve overall production quality control efficiency.
