The core advantage of this product lies in its non-contact measurement technology, which avoids scratching precision workpieces such as polished metal parts and semiconductor components. Its IP54 dust and water protection grade is suitable for harsh workshop environments. The built-in lithium battery provides 8 hours of continuous working time, meeting the needs of outdoor or non-power-supply on-site detection. The Bluetooth 5.0 and USB3.0 interfaces support fast data transmission with computers, and the built-in analysis software can automatically calculate geometric tolerance parameters such as arc radius, step height, and contour degree, reducing the workload of professional technicians.
The main machine dimensions are 320mm × 240mm × 180mm, with a net weight of 3.2kg, making it easy for a single person to carry. The measuring stroke of X-axis is 200mm, Y-axis is 100mm, Z-axis is 50mm, and the measurement accuracy can reach ±0.5μm, meeting the detection requirements of most medium-precision workpieces. It supports two power supply modes: DC12V adapter and 18650 lithium battery pack, which can be replaced quickly. The supporting analysis software is compatible with Windows and Mac operating systems, and can export detection data in CAD, PDF and Excel formats for subsequent process analysis.
This product is widely used in automotive parts manufacturing (such as crankshaft, camshaft contour detection), hardware mold processing, precision electronic component inspection, aerospace fastener detection and other scenarios. It can complete the rapid detection of workpiece arc, step height, arc radius, surface roughness and other parameters on the workshop site, replacing part of the on-site detection needs of traditional projectors and three-coordinate measuring machines, greatly improving the detection efficiency of production line sampling and incoming material inspection.
