The core advantage lies in its integrated portable design, abandoning the fixed installation constraints of traditional desktop equipment. It is equipped with a 2μm diamond stylus to ensure nano-level precision detection, and has an 8-hour long-lasting battery life to support all-day field operations. The high-strength aluminum alloy housing can resist the harsh workshop environment, and supports Bluetooth wireless data synchronization to the PC for later analysis. It comes with one-click calibration function to simplify the operation process, solving the industry pain points of difficult and long-cycle inspection for small and batch workpieces, and is compatible with ISO and GD&T international inspection standards to adapt to multi-industry inspection needs.
Detailed parameters: overall size 220mm×180mm×100mm, net weight 1.2kg; X/Y axis measurement stroke is 100mm, Z axis stroke is 50mm; vertical resolution reaches 0.01μm, measurement accuracy is ±0.05μm; using R=2μm natural diamond test probe, supports multiple types of detection such as roughness, profile and step height; built-in 3.5-inch IPS high-definition display, supports offline viewing of detection data; equipped with USB-C and Bluetooth 5.0 communication interfaces, compatible with Windows/macOS systems; data storage capacity supports saving more than 1000 sets of inspection reports; working temperature range is 10℃ to 35℃, relative humidity 30%-70% without condensation.
Applicable scenarios include cavity profile inspection in mold manufacturing, geometric tolerance inspection of aerospace precision parts, size verification of auto parts stamping parts, precision inspection of medical device parts, and portable measurement in university research institutes. It can be adapted to CNC processing sites, outsourced processing factories, parts warehouses and other scenarios, and can carry out inspection work quickly without fixed installation, helping enterprises shorten the inspection cycle and improve production quality control efficiency.
