The core advantage lies in the fully automatic inspection process, supporting integration with standard belt conveyors for online batch inspection. It is equipped with line laser scanning technology to achieve non-contact high-speed inspection, and can complete accurate measurement of 60 workpieces per minute. It adopts IP65 protection grade to adapt to the harsh production environment of the workshop, and is equipped with PROFINET and Ethernet/IP industrial communication interfaces that can directly connect to the production line control system. It is equipped with a real-time quality control analysis system that can give early warning of unqualified products in real time, solving the industry pain points of delayed quality inspection and high labor costs in large-scale batch production, and supports custom inspection procedures to adapt to the inspection needs of different specifications of workpieces.
Detailed parameters: overall size 1800mm×1200mm×1800mm, net weight 850kg; using line laser non-contact scanning technology, sampling resolution 0.5μm; X/Y axis measurement stroke 500mm×300mm, Z axis stroke 150mm; single batch inspection speed up to 60 pieces/minute, supports one-click switching of different workpiece inspection procedures; equipped with automatic loading and unloading docking interface, compatible with standard belt conveyors; protection grade IP65, can resist workshop dust, oil and splashing liquid; supports PROFINET and Ethernet/IP industrial communication protocols, can directly connect to the factory MES system; equipped with real-time quality analysis system, can generate batch inspection reports and unqualified product early warning data; working temperature range 10-40℃, relative humidity 30%-80% RH, need to be equipped with 380V three-phase stabilized power supply.
Applicable to online quality inspection of auto parts stamping parts, dimensional inspection of engineering machinery structural parts, size accuracy verification of 3C electronic shells, batch inspection of hardware accessories, online quality control of home appliance parts production lines and other scenarios. It can be directly integrated into the automated production line to realize unmanned operation of the whole process from workpiece production to quality inspection, greatly improving the quality inspection efficiency of batch production, reducing the error rate and labor cost of manual quality inspection, and helping enterprises realize intelligent manufacturing upgrading.
