This machine stands out with its integrated towable frame, allowing quick relocation between construction sites without specialized lifting equipment. Its wear-resistant Q235 carbon steel frame and hardened alloy roll wheels ensure long service life and consistent pipe quality. The semi-automatic control system is easy to operate, requiring minimal operator training without advanced technical skills. It features adjustable forming speed to adapt to different concrete mix ratios, producing pipes with compressive strength meeting national standard GB/T 11836-2009. Additionally, it has a low noise design that complies with regional construction site environmental regulations, reducing disturbance to nearby residents during operation.
The overall dimensions of the machine are 4.2m in length, 1.8m in width, and 2.2m in height. The main motor delivers 11kW of power with an adjustable speed range of 0-30rpm. The roll wheel diameter is 600mm, compatible with pipe diameters from 300mm to 800mm and maximum pipe length of 2.5m. The total operational weight is 2.8 tons, and it operates on a standard 380V 50Hz 3-phase power supply. The standard production output ranges from 8 to 12 finished pipes per 8-hour work shift. The machine is equipped with a manual hydraulic demolding system, and the protective grade of electrical components reaches IP54 to resist dust and water splashes on construction sites.
This small mobile cement pipe maker is primarily applied in rural agricultural irrigation projects, small-town drainage system renovations, temporary construction site drainage facilities, and DIY residential landscape drainage. It is suitable for small construction contractors, individual farmers, and township infrastructure teams that require small-batch, on-site production of precast cement pipes. Typical use cases include installing irrigation pipelines for farmlands, building temporary drainage ditches for construction sites, and laying small-diameter water supply pipes for rural drinking water safety projects. It can also be used to produce decorative cement pipes for garden and park landscape designs.
