This fully automatic equipment solves the pain points of high labor intensity, low production efficiency and inconsistent product quality of traditional manual and semi-automatic equipment. Its industrial CNC control system can store hundreds of product production parameters, realizing one-click switching between different component specifications, reducing the need for skilled workers. The servo hydraulic system provides precise and stable forming pressure, ensuring the dimensional accuracy and compressive strength of each precast component meet industrial standards. The fully enclosed production environment reduces dust and noise pollution, meeting modern factory environmental protection requirements. The automatic fault alarm and maintenance reminder function improves equipment operation stability and reduces downtime, while the remote monitoring function allows enterprise managers to grasp production status in real time.
Forming pressure adjustable between 200-500kN, suitable for production of various large and medium-sized precast components; Production efficiency reaches 3000-5000 pieces per hour for standard precast blocks; Total weight 8500kg, requires fixed foundation construction; Overall dimensions 12000mm (length) × 4500mm (width) × 3200mm (height); Power supply is 380V 50Hz three-phase industrial electricity; Fuselage made of heavy-duty welded steel frame with a thickness of 12mm; Automatic feeding, conveying, forming and demolding integrated system; Industrial CNC touch screen with multi-language operating interface; Equipped with a modular mold library supporting 20+ component specifications; Servo hydraulic system with energy recovery function, saving 30% of energy compared to traditional hydraulic systems.
Mainly applicable to large-scale precast building material factories, bridge construction projects, high-rise building construction, industrial workshop construction, and municipal engineering projects. It can produce various types of precast concrete components such as beams, columns, wall panels, drainage pipes, and curb stones, meeting the large-scale and standardized material needs of modern construction projects. It is also suitable for large-scale building material enterprises that need to achieve intelligent production, helping enterprises improve production efficiency, reduce labor costs, and improve product quality consistency.
