The core advantages of this machine include high pipeline density, stable production quality and high production efficiency. It adopts the suspended roller molding process, which makes the cement slurry fully compact and the pipe anti-seepage performance reaches the national standard for municipal pipelines. The PLC semi-automatic control system reduces the difficulty of operation, and the operator only needs 3 days of training to master the operation skills. It is equipped with a dust removal system to reduce production dust pollution, and the thickened Q355 structural steel body improves the service life by 40% compared with ordinary steel bodies. It does not need to replace a large number of molds to adjust the pipe diameter range, reducing mold investment costs.
The rated host power is 22kW, the maximum pipe diameter is 1800mm, the single pipe molding cycle is 15-20 minutes, the applicable pipe wall thickness is 50-120mm, and it is compatible with ordinary Portland cement, graded sand and gravel, HRB400 reinforcing steel bars and other raw materials. The control mode is PLC semi-automatic touch control, the total net weight is 8500kg, the overall dimensions are 6500×2200×2800mm, the power supply specification is 380V 50Hz 3-phase AC, it can produce pipes with a length of 2-6m, and the mold replacement time is ≤30 minutes. It is equipped with 4 sets of different caliber molds as standard, and the body is made of thickened Q355 structural steel.
It is suitable for municipal drainage and sewage pipelines, supporting pipelines of urban underground comprehensive pipe galleries, small industrial wastewater conveyance pipelines, etc. The target industries include municipal engineering construction, urban pipe network transformation, and industrial infrastructure projects. It can help large and medium-sized construction enterprises efficiently produce qualified large-diameter cement pipelines and meet the procurement needs of large-scale projects.
