The spiral extrusion molding technology ensures that the cement pipes have uniform porosity and good permeability, meeting the requirements of seepage and filtration. The vertical structure saves floor area, which is suitable for small operation sites. The induction control system can automatically adjust the extrusion speed according to the concrete consistency, ensuring the consistency of pipe quality. The wear-resistant die has long service life, and the maintenance cost is low. The machine can produce continuous cement pipes without joints, improving the seepage effect of the pipes.
It can process permeable cement pipes with diameter ranging from 200mm to 800mm, with adjustable pipe length between 1000mm and 1500mm. The main motor power is 5.5kW, with an extrusion speed of 0.5m per minute. The overall dimensions are 2500mm in length, 1600mm in width and 2800mm in height, with a total weight of 2.8 tons. It uses 380V 50Hz three-phase alternating current as power supply, and is equipped with a semi-automatic control panel. The die is made of wear-resistant cast steel, with a service life of up to 8000 molding times. The machine can adjust the porosity of the pipes by changing the extrusion gap, meeting different seepage requirements.
This machine is suitable for producing permeable cement pipes for garden irrigation, urban green space seepage, rural sewage filtration, landscape water circulation and other environmental protection projects. It is ideal for greening companies, sewage treatment stations and small-scale environmental protection projects, and can produce high-quality permeable cement pipes that meet environmental protection standards.
