Adopts two-stage compression refrigeration system to achieve stable temperature control with high precision, and the touch-screen human-machine interface simplifies operation. It supports programmable test programs, can store up to 100 sets of test parameters, and has remote monitoring function to view test data in real time. Compared with traditional test chambers, it has faster temperature rise and drop speed, lower energy consumption, and solves the problems of large temperature fluctuation and low test efficiency. It is also equipped with complete safety protection devices to ensure safe and reliable operation during long-term testing.
The inner container size is 1000*1000*1000mm, and the overall external size is 1800*1800*2200mm with a net weight of 850kg. The insulation layer is made of 100mm thick polyurethane foam for good heat preservation effect. The observation window is 300*400mm with built-in LED lighting device. The refrigeration method adopts air-cooled type, and the compressor is imported from well-known brands. The power supply parameters are 380V 50Hz three-phase, and the rated power is 12kW. It also supports custom adjustment of temperature rise and drop rates according to test requirements.
It is widely used in the reliability testing of electronic chips, circuit boards, auto parts, new energy battery packs and other products. It can be used in university R&D laboratories, third-party quality inspection institutions, and mass production testing lines of manufacturing enterprises. Typical application scenarios include high and low temperature aging testing of consumer electronics, thermal stability testing of automotive electronic components, and performance verification of aerospace materials under extreme temperature environments.
