This product adopts manual pressure and temperature adjustment design, allowing users to freely configure parameters according to sample types and preparation needs. It supports compatible with most common thermosetting mounting materials on the market, reducing the cost of material matching. The compact body structure saves laboratory space, and the rust-proof spray coating body extends the service life of the equipment. It eliminates the complicated operation steps of fully automatic equipment, making it easy to get started for novice operators, and can complete 8-10 sample mountings per hour to meet daily small-batch preparation needs.
The overall size of the equipment is 550mm × 450mm × 600mm, with a maximum mounting sample diameter of 80mm. The mounting pressure can be adjusted steplessly between 0-20MPa, and the temperature control range is from room temperature to 180°C with an adjustment accuracy of ±2°C. The rated power is 1.5kW, and it uses a 220V 50/60Hz universal power supply. The net weight is 85kg, and it adopts natural air cooling without additional water pipe connection, reducing the installation complexity of the equipment without relying on fixed water supply facilities.
It is mainly suitable for metallurgical teaching experiments in colleges and universities, small metal processing factories for daily sample preparation, personal metallographic hobby research, and small third-party testing institutions for simple sample mounting work. It can complete the mounting of common metal samples, plastic samples and ceramic samples, providing qualified basic samples for subsequent metallographic microscope observation and failure analysis.
