This multi-station mounting press adopts independent station control technology, allowing each station to set different heating temperature, pressure and holding time according to the sample requirements, realizing flexible and diverse sample preparation. The centralized water-cooling system reduces the overall preparation cycle of batch samples, improving work efficiency by 200% compared to single-station equipment. It supports cloud data upload and remote monitoring, meeting the data traceability requirements of large laboratories. It is equipped with a fault automatic diagnosis system, which can quickly locate and troubleshoot equipment failures, reducing maintenance time. The cast steel body ensures stable operation under long-term high-load conditions.
Voltage: 380V 50Hz (Optional 220V), Single Station Heating Temperature Range: Room Temperature to 220℃ with closed-loop control, Single Station Pressure Range: 0-20MPa with closed-loop adjustment, Programmable Process Groups: 20 custom programs per station, Mounting Chamber Specifications: Φ25/Φ30/Φ40/Φ50mm optional molds, Body Material: High-strength cast steel, Net Weight: 280kg, Gross Weight: 320kg, Packaging Dimensions: 200*120*100cm, Safety Configurations: Station independent safety lock, centralized overheat protection, fault automatic diagnosis, Applicable Mounting Materials: Thermosetting resin, epoxy resin, phenolic plastic, composite materials
This equipment is suitable for automotive parts mass metallographic detection, third-party testing institutions' large-scale sample preparation, metal processing plant mass quality control, and scientific research institutes' batch sample R&D. It can prepare metallographic samples for large-batch metal parts, automotive components, composite materials and other products, providing efficient and high-quality sample support for mass production quality control and large-scale material analysis. It meets the testing standards of national third-party testing institutions and is an essential equipment for large-scale material testing workshops.
