Adopts dual independent sensing channel design, which can accurately measure cold water and heat consumption data at the same time without interfering with each other; is equipped with dual LCD displays, which respectively display cold water consumption and heat data at a glance; adopts brass one-piece molding shell, corrosion-resistant and anti-leakage; supports data export function, which can export cumulative usage data to U disk for analysis; meets EU RoHS environmental protection standards, uses non-toxic and harmless materials, adapting to the use needs of high-end commercial scenarios.
The caliber is DN20~DN25, the overall dimensions are 190mm × 90mm × 70mm, and the overall weight is 1.4kg; the working environment humidity is 30%~90%RH, and the protection level is IP65; the dual-channel flow measurement range is 0.01~15 m³/h (cold water) and 0.01~12 MW (heat) respectively; the battery is 3.6V ER18505 lithium-thionyl chloride battery, with standby power consumption ≤0.5μW; supports local data storage for more than 10 years, supports manual zero clearing and batch calibration functions; can expand RS485 communication module to realize remote data transmission.
It is applicable to hotel rooms, fitness clubs, high-end apartments and catering store cold and hot water and heating heat metering scenarios, which can help operators accurately count energy consumption data of different areas, provide basis for charging management and energy saving transformation, and provide users with clear cold and hot water and heat consumption bills, improving service transparency.
