The core technical highlight lies in its flameproof housing design certified by ATEX and IECEx, using one-piece cast aluminum alloy molding technology, capable of withstanding corrosive gases and dust in chemical environments. Equipped with high-brightness SMD 2835 LED light sources, it emits light uniformly without dark areas, with a visual distance of more than 500 meters, and can clearly transmit warning signals even in harsh weather conditions. It supports optional red, yellow, and green colors to meet different warning level requirements; the wide voltage input design adapts to multiple power supply modes in industrial sites, and the wall-mounted and column-mounted installation methods can be flexibly switched. In addition, the product has built-in over-temperature protection and short-circuit protection devices, which effectively improve operational stability. With a service life of more than 100,000 hours, it greatly reduces enterprise maintenance costs and solves the pain points of traditional signal lights being prone to failure and difficult to maintain in hazardous environments.
The main body size of the product is 160mm (diameter) × 220mm (height), with a net weight of 1.8kg; the housing is made of 5mm thick cast aluminum alloy, surface treated with electrostatic spraying, with a protection rating of IP68, which can withstand 24 hours of immersion in 10-meter deep water without leakage. The light source is SMD 2835 LED, with a single brightness of 12lm and a luminous angle of 120°; the operating voltage supports AC 110-240V 50/60Hz or DC 12-24V, with a power consumption of only 8W, which reduces energy consumption by more than 70% compared with traditional incandescent lamps. The visual distance is ≥500 meters in sunny environments and ≥150 meters in foggy environments; the operating temperature range is -40°C to +60°C, which can adapt to extremely cold and high-temperature industrial scenarios; certifications include ATEX Ex d IIB T6 Gb, IECEx Ex d IIB T6 Gb, CSA C/US; the service life is ≥100,000 hours, and the mean time between failures (MTBF) is ≥50,000 hours.
It is mainly used in hazardous environments with flammable and explosive gases or dust, such as oil refineries, natural gas treatment stations, coal mine underground operation areas, and chemical production workshops, as core equipment for equipment fault warning, safety area division, emergency evacuation channel identification, and hot work area warning. In addition, it can also be applied to marine high-corrosion environments such as offshore oil drilling platforms and liquefied natural gas storage tanks, as well as remote unattended oil pipeline transfer stations, providing clear and reliable safety signal guidance for on-site operators and equipment monitoring systems. In emergency response to sudden accidents, this signal light can quickly start warning, guide personnel to evacuate safely, and effectively reduce accident risks.
