Focusing on low cost and ease of use, this machine adopts a durable body structure of cast iron and stainless steel, and is equipped with a basic photoelectric yarn breakage detection device, which can effectively avoid invalid winding after yarn breakage. The semi-automatic operation mode does not require complicated training to use. It adapts to conventional textile yarns with a count of 20-60 Ne, and has an efficiency improvement of more than 60% compared with pure manual winding. At the same time, the wound bobbin has uniform density, which can be directly adapted to subsequent weaving processes and reduce the frequency of parking and changing yarn in subsequent processes.
The detailed parameters include a winding speed of 600-800 meters per minute, applicable yarn count range of 20-60 Ne, power supply specification of 220V 50/60Hz, total machine weight of 120kg, overall dimensions of 1200mm (length) × 800mm (width) × 1500mm (height), supporting bobbin length of 100-200mm, adopting cross winding forming method, equipped with basic photoelectric yarn breakage detection system, the main body of the machine is cast iron frame with stainless steel vulnerable parts, and has basic overvoltage protection function, which can adapt to conventional textile yarns such as cotton, polyester and viscose.
It is mainly suitable for small and medium-sized cotton mills, individual knitting workshops, small towel weaving mills and other scenarios. It can be used to wind weft bobbins for weaving, replacing manual winding operations, improving the degree of production standardization. It is suitable for enterprises that mass produce conventional textile fabrics, and can also be used as an auxiliary winding equipment for large textile factories to supplement temporary production capacity needs.
