This micro hardness tester solves the critical pain point of testing small, thin, or delicate materials where standard hardness testers cannot produce valid indentations. Its high-magnification optical imaging system automatically measures indentation diagonal length with a precision of 0.001mm, ensuring highly accurate hardness calculations. The closed-loop force control system maintains test force stability within ±0.5% of set values, eliminating variation caused by manual loading. The integrated data management system stores up to 5000 test records with full sample metadata, and the USB and RS232 interfaces support seamless integration with laboratory information management systems (LIMS). It also includes automatic focus adjustment and sample stage positioning to streamline testing workflows for high-volume lab environments.
Optical Magnification: 100x-400x; Indentation Measurement Accuracy: ±0.001mm; Test Force Range: 0.01kgf to 1kgf; Sample Stage Travel: X-axis 100mm, Y-axis 100mm; Power Supply: 110/220V AC, 50/60Hz; Net Weight: 25kg; Overall Dimensions: 600mm x 500mm x 700mm; Calibration Standard: NIST-traceable micro hardness blocks (HV100, HV500, HV1000); Software: Included LIMS-compatible data analysis software; Operating Humidity: 20% to 60% RH (non-condensing).
This Vickers micro hardness tester is used in aerospace manufacturing to test the hardness of turbine blade coatings, in medical device production to verify the hardness of surgical implant materials, in semiconductor packaging to test the hardness of solder joints, and in academic research labs to characterize the mechanical properties of thin film materials. It is also ideal for quality control of small precision parts, such as watch components, micro screws, and electronic connector pins.
