This downhole wireless inclinometer has the core advantage of high-precision measurement with an accuracy of ±0.02°, meeting the precision requirements of professional drilling monitoring. It adopts 316L stainless steel shell and IP68 waterproof design, which can resist corrosion and water immersion in underground harsh environments. The low-power design provides up to 12 months of continuous monitoring life, reducing the frequency of battery replacement. It supports wireless transmission of 433MHz or 915MHz frequency, with a transmission distance of 500 meters underground, avoiding the problem of cable winding and damage in traditional wired inclinometers. It also has a built-in large-capacity data storage function, which can store 50000 sets of measurement data, providing data support for later analysis.
The downhole wireless inclinometer has a measuring range of ±90° with an accuracy of ±0.02°, meeting the precision requirements of professional downhole monitoring. It has a maximum downhole depth of 1500 meters, and supports optional wireless transmission frequencies of 433MHz or 915MHz, with a transmission distance of 500 meters underground. The device is made of 316L stainless steel, with a dimension of Φ80 x 350 millimeters and a weight of 2.5 kilograms. It has a built-in data storage capacity of 50000 sets of data, and the operating temperature range is -20℃ to 60℃. It is powered by built-in high-performance batteries, providing up to 12 months of continuous monitoring life, and supports remote data viewing and parameter configuration.
This downhole wireless inclinometer is widely used in oil and gas drilling well deviation monitoring, coal mine roadway attitude detection, geological exploration borehole tilt monitoring, shield tunnel construction downhole attitude adjustment, underwater structure tilt monitoring of offshore drilling platforms and other scenarios. It is an essential professional monitoring tool for underground engineering and drilling operations, helping to ensure the safety and efficiency of construction.
