The core advantage of this clamp-on ultrasonic flowmeter is its non-invasive installation, which will not damage the original pipeline and will not cause medium leakage during installation. It supports portable and fixed installation, and the built-in battery can last for more than 2 years of continuous use. The LCD digital display can display real-time flow, cumulative flow and other data in Chinese and English, and the built-in data storage function can store up to 100,000 sets of flow data for subsequent data analysis. It has a built-in signal amplifier, which can effectively improve the measurement accuracy in complex pipeline environments, and supports wireless data transmission through Bluetooth or LoRa for remote monitoring.
The detailed specifications are as follows: The applicable pipe diameter range is 15~600mm, and the accuracy is ±1% FS. The transducer is made of nylon and stainless steel, which has good wear resistance and corrosion resistance. The power supply adopts 4*D-type alkaline batteries, which can be replaced easily, and the solar charging version is suitable for long-term outdoor use. The display is a 2.4-inch LCD screen, which can display multiple parameters such as flow rate, cumulative flow, flow velocity and medium temperature. The protection grade is IP67, which can resist rain and splashing water. The wireless transmission distance of Bluetooth is 10 meters, and the LoRa version can realize long-distance transmission of more than 5km. The overall size is 180mm*120mm*60mm, and the weight is about 0.8kg.
This clamp-on ultrasonic flowmeter is suitable for temporary flow measurement of existing pipelines, such as emergency flow detection of municipal water supply pipes, flow monitoring of oil transportation pipelines in petrochemical enterprises, and flow measurement of agricultural irrigation pipelines. It can also be used for long-term online monitoring of industrial circulating cooling water, hotel domestic water flow detection, and fire protection system flow monitoring. It is very suitable for users who do not want to modify the original pipeline or have high installation cost requirements, providing a convenient and low-cost flow measurement solution.
