This orifice plate flowmeter has multiple core advantages. First, the simple structure and low manufacturing cost make it a cost-effective flow measurement solution. Second, it can adapt to a wide range of medium types, including gas, liquid and steam, and can work in high-temperature and high-pressure environments. Third, the integrated design integrates the sensor and the display, which is easy to install and debug. It also has no moving parts, so it has a long service life and low maintenance costs.
Detailed specifications include: flow measurement range covers 100-10000 m³/h, with an accuracy grade of ±1.0% of reading, which meets the requirements of conventional large-flow measurement. The operating pressure ranges from PN10 to PN60, adapting to high-pressure pipeline conditions. The working temperature ranges from -40℃ to +400℃, which can meet the measurement needs of high-temperature steam and gas. The main body is made of carbon steel or optional 304 stainless steel, which has good mechanical strength and corrosion resistance. It adopts ANSI/GB standard flange connection, and the interface specifications range from DN50 to DN3000. The external display is powered by 24V DC, and supports 4-20mA and pulse output signals, which can be connected with industrial control systems.
This economical orifice plate flowmeter is mainly suitable for large-flow measurement of steam in thermal power plants, gas measurement in metallurgical enterprises, water flow measurement in mining areas, and oil flow measurement in large-scale oil depots. Typical application cases include: measuring the steam flow of thermal power generation boilers, measuring the compressed air flow of metallurgical production lines, measuring the water supply flow of mining areas, and measuring the oil flow of large-scale oil depots. It can also be used in the flow measurement of urban natural gas pipelines, providing accurate flow data for urban gas supply and metering.
