This insulated concrete roof tile addresses two key pain points for property owners: high energy costs and poor indoor comfort. The built-in polystyrene insulation layer delivers excellent thermal performance, with a thermal conductivity of less than 0.032 W/(m·K), which significantly reduces heat transfer through the roof cavity. It also provides effective sound isolation of up to 35dB, reducing external noise pollution like traffic and rainfall for indoor occupants. Its low water absorption rate of less than 8% ensures long-term insulation performance without degradation from moisture exposure. The dry clip installation system speeds up on-site installation, eliminating the need for messy wet mortar and reducing labor time by up to 25% compared to traditional wet installation methods. The tile meets LEED green building certification requirements, making it a sustainable choice for eco-friendly construction projects.
Each insulated concrete roof tile measures 450mm in length, 350mm in width and 27mm in total thickness, including the 15mm polystyrene insulation layer bonded to the 12mm AAC base tile. The single tile weight is approximately 4.5kg, with approximately 7.8 tiles required to cover 1 square meter of roof area. The tile has a minimum compressive strength of 38MPa, meeting the requirements for most residential and light commercial roofing applications. It holds both ISO 14001 environmental certification and LEED compliance, making it eligible for green building incentives. The thermal insulation performance meets EN 12524 standards, while the sound isolation performance exceeds industry standards for residential roofing. It is compatible with both wooden and metal purlin systems, with a recommended clip spacing of 300mm for secure installation.
This insulated AAC concrete roof tile is ideal for cold climate regions, energy-efficient green building projects, multi-story residential apartments and commercial office buildings. It is particularly well-suited for properties located in areas with extreme temperature fluctuations, where reducing heating and cooling costs is a top priority. It can be used for both new construction and roof replacement projects, and is compatible with most standard roofing underlayment materials. The dry clip installation system makes it a great choice for prefabricated building projects, where fast and clean installation is required. The tile’s LEED compliance makes it a popular choice for developers seeking to earn green building certifications and qualify for government incentives for sustainable construction.
