The core advantage of this equipment lies in its anion exchange membrane separation technology, which can separate the anode and cathode electrolytes, avoiding the mixing of metal ions and improving the deposition precision to ±0.1μm. The PLC remote monitoring system supports real-time monitoring of operating parameters such as current, voltage and deposition thickness, and can automatically adjust the operating parameters to ensure the stability of the deposition process. The PP polypropylene tank has excellent corrosion resistance, adapting to various acidic and alkaline electrolytes. Compared with traditional electroplating processes, this equipment does not produce harmful waste gas and waste liquid, meeting the requirements of environmental protection policies and reducing the cost of waste treatment.
The main technical specifications of this product include: maximum deposition area of 1000mm (length) * 600mm (width), deposition precision up to ±0.1μm, configured with 8kW adjustable DC power supply, deposition efficiency reaching more than 95%. The overall dimensions are 3500mm (length) * 2200mm (width) * 2000mm (height), with a net weight of 4.5 tons. The equipment is equipped with a liquid circulation system and a temperature control system, which can maintain the stability of the electrolyte and improve the uniformity of the coating. The service life of the core membrane and electrode assembly can reach more than 12000 hours under normal operating conditions.
This polymer membrane electrolytic deposition equipment is mainly applicable to the following scenarios: 1. Precision electronic component electroplating, producing high-precision metal coatings for circuit boards and electronic connectors; 2. Hardware jewelry electrolytic deposition, producing uniform and bright metal coatings for jewelry and hardware accessories; 3. New energy battery electrode production, preparing high-quality nickel and copper coatings for lithium battery electrodes; 4. Metal surface treatment, improving the corrosion resistance and aesthetics of metal parts. It can meet the high-precision and high-efficiency deposition requirements of various metal materials.
