It is equipped with a 200mm extended magnetic detection rod, which can easily detect the anti-corrosion layer thickness of hard-to-reach areas such as high-altitude steel structures and ship inner walls. It adopts a heavy-duty anti-corrosion plastic shell and rubber anti-slip grip, adapting to extreme outdoor operation environments from -20℃ to 60℃. It is equipped with a built-in 1800mAh rechargeable lithium battery, which can be used continuously for 40 hours after a single charge. The backlit LCD screen can clearly read data in strong light, supports 2000-group data storage and one-key export, and the accuracy reaches ±2%+2μm, meeting the high-precision detection requirements of heavy industrial anti-corrosion layers. Compared with traditional short-rod thickness gauges, it covers more long-distance detection scenarios.
Detection Principle: Magnetic Induction; Measuring Range: 0-5000μm; Measurement Accuracy: ±(2% + 2μm); Extended Probe Rod Length: 200mm; Power Supply: 1800mAh Rechargeable Li-ion Battery; Charging Time: 2 Hours; Continuous Usage Time: 40 Hours; Operating Temperature Range: -20℃ to 60℃; Display: Backlit LCD Screen; Data Storage: 2000 Measurement Records + USB Export; Housing Material: Heavy-duty Anti-corrosion Plastic + Rubber Anti-slip Grip; Net Weight: 380g; Product Dimensions: 280mm (L) × 70mm (W) × 40mm (H); Auto Power-off Time: 5 Minutes of Inactivity; Calibration: Standard Block Calibration; Compatible Substrates: Ferrous Metals (Steel, Iron); Applicable Coatings: Zinc-rich Primer, Epoxy Coating, Polyurethane Coating
It is suitable for shipbuilding and maintenance, bridge steel structure anti-corrosion engineering, heavy machinery manufacturing and oil and chemical storage tank anti-corrosion detection. It can easily detect the anti-corrosion layer thickness of high-altitude and long-distance steel structures, helping enterprises control the construction quality of anti-corrosion engineering and avoid steel structure corrosion caused by insufficient anti-corrosion layer thickness. It can also be used for regular anti-corrosion detection of large outdoor equipment to extend the service life of equipment.
