It adopts electromagnetic induction non-contact metering technology, which is not affected by water impurities and turbidity, with metering accuracy up to 0.5 level, suitable for large flow industrial water metering. It is made of cast iron epoxy coating material, corrosion-resistant and anti-aging, adapting to complex industrial environments, and has an IP68 protection grade that can be used in outdoor underwater environments for a long time. It is equipped with 4G Cat.M1 communication technology, with wide signal coverage, compatible with global mainstream 4G networks, and optional external 220V power supply or built-in lithium battery power supply, with a battery life of more than 3 years. It supports remote parameter configuration, automatic fault diagnosis and alarm push, can monitor pipe network pressure and flow changes in real time, and early warn of pipe network leakage, pipe burst and other safety accidents, greatly reducing the operation and maintenance costs and safety risks of industrial water use.
The nominal pipe diameter is DN200, the dimensions are 850mm (length) × 560mm (width) × 420mm (height), with a net weight of 56kg, maximum working pressure of 1.6MPa, applicable water turbidity up to 10000NTU, adjustable data upload interval from 1 to 60 minutes, supporting communication protocols such as MQTT and HTTP, compatible with industrial Internet platforms and smart municipal management systems, and supporting multi-account permission management to realize multi-department collaborative management.
It is mainly used in large industrial factory water supply, municipal pipe network main pipe metering, industrial park centralized water supply, water treatment plant influent metering and other scenarios, serving users such as industrial enterprises, municipal water affairs departments, industrial park managers and so on. It can realize visual management of the whole process of water use, accurately calculate the water use cost of each production workshop, help enterprises optimize water use processes, and achieve water conservation and consumption reduction goals.
