Passed Ex d IIB T6 explosion-proof certification, suitable for flammable and explosive places; IP68 waterproof and dustproof, can withstand long-term immersion in water and harsh outdoor environments; Adopts high-stability electronic metering technology, no moving parts, long service life; LORA/Wi-Fi 6 dual communication mode, suitable for different long-distance and short-distance transmission scenarios; 8-year long battery life, no frequent replacement; Support remote fault warning and explosion-proof status monitoring; Food-grade and corrosion-resistant 316 stainless steel measuring chamber, suitable for non-corrosive industrial water and tap water; Simple installation and maintenance, solving the safety hazards and difficult maintenance of traditional water meters in flammable and explosive outdoor scenarios.
DN15 model: 200mm (length) × 90mm (width) × 130mm (height), weight 2.5kg; DN50 model: 350mm × 120mm ×160mm, weight 8kg; DN100 model: 500mm × 160mm ×200mm, weight 22kg; Operating pressure range: 0.1-2.0MPa; Accuracy class: Class B; Communication mode: LORA 470MHz/Wi-Fi 6 dual-mode optional; Battery: 3.6V lithium iron phosphate explosion-proof battery; Protection rating: IP68 + Ex d IIB T6; Maximum flow rate: DN15:2.5m³/h, DN50:50m³/h, DN100:200m³/h; Operating temperature range: -20℃ to 60℃; Compatible with both threaded and flange connection standards, suitable for different pipeline installation scenarios.
Mainly applicable to chemical parks, gas stations, oil and gas gathering stations, industrial zones with flammable and explosive gas or dust, as well as outdoor water supply projects in harsh environments such as cold regions and coastal areas. It can provide safe and accurate water metering for water supply systems in these scenarios, support real-time remote monitoring of water consumption and fault warning, ensure the safe operation of water supply equipment, and meet the safety certification requirements of special industrial scenarios, effectively solving the safety risks and metering accuracy problems of traditional water meters in flammable and explosive outdoor environments.
