Using electromagnetic induction metering principle without mechanical obstruction, zero pressure loss, long service life; Class 0.5 high accuracy compliant with international industrial metering standards; Flange mounting suitable for large-caliber water pipelines; Support external power supply and battery backup mode; Real-time monitoring of flow rate, total water consumption, and pipeline status; Remote fault diagnosis and alarm functions; Data encryption transmission to ensure data security; Compatible with industrial water supply management platforms, supporting large-scale networking management, solving the pain points of large-flow water metering inaccuracy, high maintenance frequency, and difficult remote management in industrial and municipal scenarios.
DN50 model: Flange diameter 165mm, overall length 380mm, weight 12kg; DN100 model: Flange diameter 210mm, overall length 520mm, weight 28kg; DN300 model: Flange diameter 540mm, overall length 1200mm, weight 210kg; Operating pressure range: 0.2-2.5MPa; Accuracy class: 0.5 level; Communication mode: 4G CAT1/NB-IoT optional; Battery: 3.6V lithium battery, external AC 220V power supply optional; Measurable flow range: DN50: 10-100m³/h, DN100: 40-400m³/h, DN300: 800-8000m³/h; Protection rating: IP67, suitable for indoor and outdoor industrial environments; Compatible with flange connection standards of national and international water pipelines.
Mainly applicable to municipal water supply pipe networks, industrial production water consumption systems, large-scale commercial complexes, water treatment plants, and agricultural irrigation large-scale water distribution systems. It can provide accurate metering data for large-flow water supply, support real-time monitoring of water consumption, remote management and billing, effectively improving the management efficiency of large-scale water resources, reducing the loss of water measurement, and providing reliable data support for water supply companies and industrial enterprises to carry out water resource accounting and cost control.
