Adopting ultrasonic measurement technology, this meter has no mechanical rotating parts, reducing wear and extending service life to more than 15 years. The NB-IoT network ensures stable data transmission in areas with poor mobile signal coverage. It supports multi-point centralized monitoring, enabling managers to view real-time water consumption data of multiple meters on a unified platform. The dual power supply design ensures uninterrupted data transmission even during power outages, and its high-strength cast ductile iron material provides excellent corrosion resistance for outdoor or harsh environment installation.
Flow measurement range: 10m³/h~1000m³/h, maximum working pressure: 2.5MPa, overall dimensions vary by model (DN50: 320mm × 240mm × 180mm), net weight: 8.5kg (DN50 model), data update frequency: 1 minute customizable, backup battery lifespan: 72 hours during power outages, working humidity: 5%~95% non-condensing, compatible with ISO 7005 flange standards.
Suitable for commercial places such as large hotels, shopping malls, office buildings, industrial factories, water treatment plants, and municipal water pipe network monitoring. It can be integrated with enterprise energy management systems and municipal water supply platforms to realize real-time water consumption monitoring, intelligent billing, flow trend analysis, and abnormal water usage warning, helping enterprises reduce water waste and control operational costs.
