This instrument realizes the integration of detection and machining, avoiding the need to transport shaft parts to the laboratory for detection after machining, reducing the time and cost of intermediate links. The high-frequency strobe LED light source can avoid motion blur caused by the movement of the shaft during online detection, ensuring clear imaging and accurate measurement data. It can be linked with various types of CNC machine tools, and the built-in intelligent algorithm can automatically identify the type of shaft parts and select the corresponding detection procedure, reducing the operation threshold of on-site operators. The detection data can be directly uploaded to the MES system, realizing full traceability of production quality.
The overall size is 2000mm×1500mm×2000mm, the host weight is 450kg, the measuring accuracy is ±0.001mm within the effective measurement range, the maximum detectable shaft diameter is 250mm, the maximum detectable shaft length is 800mm, the imaging resolution is 16 million pixels, the working stroke is X:800mm, Y:200mm, Z:250mm, the power supply is 380V 50Hz, and it is applicable to ambient humidity of 40%-60% RH.
It is suitable for online detection of shaft parts in CNC machining workshops, automobile engine production lines, bearing manufacturing workshops and other automated production lines. Typical application scenarios include online detection of CNC machined crankshafts, grinding shafts, and motor shafts, realizing real-time adjustment of machining parameters during the production process, reducing the scrap rate of shaft parts and improving the overall production efficiency of the enterprise.
