LED Wall-Mounted Alleyway Light

Basic Info

The wall-mounted alleyway light features a compact and flexible design,specifically engineered to provide efficient,uniform side lighting for narrow spaces such as building alleys,stairwells,and underground garage corridors,effectively eliminating dark spots.

Key attributes

Housing Material

Die-cast aluminum housing, tempered glass cover

Optical Lens

Prismatic lens or micro-prism reflector

Light Source Type

Integrated COB LED or 2835 SMD LED

Driver Power Supply

Asymmetric rectangular light pattern

Mounting Method

Wall or pole bracket mounting

Input Voltage

AC/DC 85-305V wide voltage

Protection Rating

IP66

Power Factor

>88%

Correlated Color Temperature

4000K

Smart Control

Provides uniform vertical illuminance on walls

Customer reviews

Mike Jordan · Major Engineering General Contractor Site Manager

Large-scale projects require high installation efficiency. The modular design and quick-connect connectors of these railing lights enabled our crew to work in an “assembly-line” style efficiently. The manufacturer’s installation guide videos and detailed spacing/power calculation tools also greatly assisted with pre-planning and on-site construction, ensuring the project was completed on time and to a high standard.

Father Richard Moore · Parish Building Committee Chairman

Used for nighttime floodlighting of a historic church façade. We chose the 3000K CCT and high-CRI version. The colors and textures of the brickwork were faithfully rendered, creating a solemn and warm visual effect. The precise beam angle control prevented light 'spill' into unwanted areas, earning recognition from the heritage preservation unit.

Marcus Johnson · Municipal Engineer

After installing your modular LED street lights, the road uniformity in our district has significantly improved. Our maintenance team particularly praised the modular design: last month, a faulty module was replaced quickly in just 15 minutes without affecting nighttime traffic. The annual energy audit showed an electricity saving rate of 58%, fully meeting the project's expectations.

Product Description

Product Features:

Constructed with robust die-cast aluminum for excellent heat dissipation.Precise asymmetric light distribution concentrates light onto the pathway,minimizing light pollution and spillage.The high IP rating ensures stable operation in dusty,humid environments.Often integrates photocell or microwave sensors for energy-saving operation(light on when motion is detected).

Product Specifications:

Power range from 20W to 100W;maximum luminous flux up to 13,000 lumens.Typically features a square or elongated compact design.The adjustable mounting bracket allows for adaptation to different walls and lighting angles.

Product Applications:

Widely used in residential community alleys,campus pathways,factory/warehouse corridors,underground parking entrance/exits,stairwells,and perimeter wall auxiliary lighting.Its side-mounting characteristic effectively complements main road lighting,enhancing area security.

Frequently Asked Questions (FAQ)

Q：Will the light shine into adjacent building windows?

A：No. It uses an asymmetric rectangular beam to precisely direct light onto the alley surface, effectively preventing side spill and uplight glare, achieving a "light without seeing the fixture" effect.

Q：What are the wall requirements for installation?

A：The wall must have sufficient load-bearing capacity. Universal mounting brackets adapt to concrete, brick, or metal columns. Reliable fasteners like expansion bolts are required.

Q：Does it have a sensor? How does it save energy?

A：Microwave or PIR sensors are optional. It maintains low power (e.g., 20%) when idle and brightens upon detecting motion, achieving up to 70% energy savings.

Q：Will damp alley conditions affect its lifespan?

A：No. With an IP66 rating, it is fully dust-tight and protected against powerful water jets. The driver is moisture-resistant, ensuring long-term stable operation in damp, dusty alleys.

Q：Is it easy to repair if it fails?

A：Very easy. The cover opens quickly via clips or screws without tools. The light module and driver are separate, field-replaceable units.

Q：How do I choose the right wattage?

A：It depends on alley width and desired illuminance. For 4-6m wide alleys, 30W-60W is recommended; for 2-3m narrow alleys, 20W-30W is sufficient. Professional lighting calculations are available.
