It adopts a high-pressure hydraulic drive system, which can easily process high-strength steel and wear-resistant steel with a thickness of 20mm, and the maximum processing width can reach 3500mm, meeting the processing requirements of large-scale protective mesh and grille plates. It is equipped with a PLC intelligent control system, which supports programmed processing of batch orders to ensure the consistency of each batch of products. The heavy-duty wear-resistant mold is equipped with a single stamping force of 1000kN, and the mold service life can reach more than 500,000 times. It requires heavy-duty concrete foundation installation to ensure the stability of heavy-load operation, and is equipped with a fully enclosed safety protection cabin to avoid the risk of steel splash during processing, complying with international safety standards.
Maximum processing sheet thickness of 20mm, maximum processing width of 3500mm, punching cycle speed of 18 times per minute, main drive motor power of 75KW, total net weight of 12800kg, overall dimensions of 12000mm in length, 3800mm in width and 4500mm in height. Applicable steel types include high-strength alloy steel, wear-resistant steel, thick galvanized steel sheet and hot-rolled thick steel sheet, supporting diamond, square and special-shaped mesh processing. The control mode is PLC touch screen intelligent control, equipped with a high-pressure hydraulic station, passing CE, ISO9001 and ISO14001 certification, the total power consumption is about 100kW, and 5 sets of standard mesh molds are standard configured, with custom special-shaped molds optional.
It is suitable for heavy-duty industrial protective mesh processing, large-scale bridge building grille plate production, port loading and unloading equipment protective mesh manufacturing, heavy-duty engineering machinery protective cover production, and can also be used for national defense and military industrial metal protective mesh and large-scale storage shelf mesh plate processing. It adapts to large-scale production enterprises with an annual output value of more than 20 million RMB, and can undertake overseas large-scale engineering orders to meet strict quality and performance requirements.
