Adopting magnetic drive seal, it greatly reduces the problem of material leakage under high pressure and high temperature, helping to ensure the safety and environmental protection of production. The combined heating mode of electric jacket and thermal oil can achieve rapid temperature rise and precise temperature control, and the dual cooling system can rapidly reduce the reaction temperature to meet the needs of rapid cooling of exothermic reactions. The high-strength agitator can withstand high torque, helping to ensure uniform mixing of high-viscosity polymer materials, alleviating the pain point of uneven mixing of high-concentration materials under high pressure. The full-automatic DCS control system can store and export production data, facilitating process optimization and production traceability.
Overall dimensions: 6500mm (height) × 3200mm (diameter); Net equipment weight: 15800kg; Agitator speed range: 0~80rpm; Interface specifications: DN100 feed inlet, DN80 discharge inlet, DN150 manhole; Power configuration: 380V 50Hz three-phase; Insulation layer thickness: 120mm aluminum silicate wool; Control system: full automatic DCS with remote monitoring function; Heating power: 45kW; Cooling medium flow rate: 20m³/h; Agitator type: turbine type with high torque.
It is suitable for the synthesis of polymer materials such as plastics and rubber, the oxidation and reduction reactions of chemical raw materials, the preparation of high-pressure pharmaceutical intermediates, and the extraction of high-value-added chemical products. It can also be used for the production of new energy materials, providing a reliable high-pressure reaction platform for chemical and new energy enterprises.
