The device adopts 4-channel independent signal processing technology, which can connect 4 different types of detection probes at the same time to realize multi-area synchronous detection, improving the detection efficiency by 4 times compared with single-channel equipment. It is equipped with a 27-inch 1080P high-definition IPS display, which supports simultaneous display of 4 detection windows, and can view the detection waveform and data of different areas at the same time, which is convenient for comparative analysis. It supports wide frequency adjustment from 1Hz to 15MHz, adapting to metal workpieces of different materials and thicknesses, and can adjust detection parameters according to production needs. The device has built-in professional batch detection software, which can automatically identify defect types and positions, generate batch detection reports, and support connection with the production line management system through the Ethernet interface to realize automated quality control. It has electromagnetic shielding design, which can operate stably in industrial production sites, avoiding external electromagnetic interference affecting detection accuracy. It also supports remote monitoring and debugging, which is convenient for technical personnel to adjust detection parameters remotely.
The overall size of the device is 600mm*450mm*220mm, and it uses AC 100-240V wide voltage power supply, and can be optionally equipped with a 14.8V 5000mAh lithium-ion battery pack to meet the needs of outdoor mobile detection. It is equipped with 4 independent probe interfaces, which can connect 4 detection probes at the same time to realize multi-area synchronous detection. It supports wide frequency adjustment from 1Hz to 15MHz, and can quickly adjust detection parameters through the touch screen. It is equipped with USB 3.0, Ethernet and RS485 multiple data interfaces, which can quickly export detection data and connect to the production line management system. The device has a built-in storage function for more than 500,000 detection records, which can be classified and stored according to batches and workpiece types, facilitating quality traceability. The device shell is made of cold-rolled steel plate spraying process, with good heat dissipation performance and anti-interference ability, and it has built-in dual cooling fans to ensure stable operation for a long time.
It is mainly applicable to the online detection of steel pipe welds and pipe wall defects in the steel pipe manufacturing industry, the surface defect detection of bars and wires in the bar and wire production industry, the batch metal part detection in the auto parts manufacturing industry, and the batch workpiece quality control in the hardware products industry. It can realize automated detection in the production line without manual operation, greatly improving the efficiency and consistency of batch detection, reducing the error rate of manual detection, and helping enterprises improve product pass rate and production efficiency.
