Crafted from 6061-T6 aerospace-grade aluminum alloy, this pole delivers an exceptional strength-to-weight ratio, supporting 300kg of solar panels while remaining lightweight enough for rooftop installations. Its powder-coated finish passes 1000 hours of salt-spray testing, providing superior corrosion resistance for coastal or high-humidity regions. The adjustable angle mechanism (0°-45°) uses heavy-duty stainless steel hinges, allowing smooth adjustment and secure locking to maximize solar energy capture based on geographic location. The octagonal shape distributes wind and ice loads evenly, withstanding gusts up to 160km/h and ice loads of 10kg/㎡ with a 1.8 safety factor. It supports both ground-mounted and roof-mounted installations, with pre-drilled brackets compatible with all standard solar panel frames. Quick-assembly design reduces installation time by 30% compared to traditional poles, cutting labor costs for integrators. Its non-magnetic properties avoid interference with solar panel performance, ensuring consistent energy output.
Height options include 3m, 4m, 5m, and 6m variants, with top diameters of 70mm and bottom diameters from 140mm (3m) to 180mm (6m). Wall thickness is uniformly 3mm across all heights, balancing strength and lightweight efficiency. The adjustable angle mechanism allows 0°-45° tilt, with stainless steel hinges for long-term durability. Powder-coated finishes are available in black or silver, with a 60μm thickness to resist UV rays and corrosion. Wind resistance is tested to 160km/h, meeting AS/NZS 1170.2 structural standards, while ice load capacity is rated at 10kg/㎡ to support heavy snow accumulation. Mounting brackets fit 60-cell or 72-cell solar panels, with pre-drilled holes for quick attachment. All components undergo tensile strength, salt-spray corrosion, and load-bearing tests to meet ISO 9001 certification requirements. The pole’s lightweight design ensures roof load compliance for residential installations, with a total weight of 25kg (3m) to 45kg (6m).
Ideal for residential rooftop solar installations, where lightweight mounting structures avoid excessive roof load. Commercial buildings and industrial facilities use it for ground-mounted solar arrays, leveraging adjustable angles to maximize energy production. Remote off-grid locations like farms, mountain cabins, and telecommunication towers rely on it to support solar panels for independent power supply. Coastal regions benefit from its superior corrosion resistance, ensuring the mounting structure remains intact in high-salt environments. Utility-scale solar farms use it for large-scale installations, reducing project timelines with quick assembly. It also serves as a portable solution for construction sites, outdoor events, and emergency response operations, providing a durable mounting base for mobile solar power systems.
