This 5G communication octagonal pole offers features for telecommunication infrastructure applications. Constructed from Q355D weather-resistant steel, it provides superior toughness and corrosion resistance, withstanding extreme temperatures, heavy snow, and strong winds up to 140km/h. The three-layer surface treatment—hot-dip galvanization, zinc-rich primer, and outdoor powder coating—creates an impenetrable barrier against rust, salt spray, and UV radiation, delivering a 30-year lifespan without requiring frequent maintenance. Its 6mm thick wall and tapered octagonal cross-section provide structural rigidity, supporting up to 150kg of 5G equipment and auxiliary devices such as power supplies and lightning protectors. The integrated lightning protection system with a top-mounted grounding rod reduces signal interference and protects sensitive electronic equipment from lightning strikes. Additionally, it features modular mounting brackets that allow for flexible antenna positioning, optimizing signal coverage and reducing dead zones.
This 18m 5G communication octagonal pole features precision-engineered technical specifications tailored for telecommunication use. Its total height is 18m, with a tapered cross-section that narrows from 300mm at the base to 180mm at the top, minimizing wind load while maintaining maximum structural stability. The 6mm thick Q355D steel wall complies with GB/T 1591-2018 structural steel standards, ensuring high strength and impact resistance. The three-layer surface treatment includes a 120μm hot-dip galvanized layer, 40μm zinc-rich primer, and 30μm outdoor powder coating, meeting ISO 1461 and ASTM A123 corrosion protection standards. The base flange measures 500mm x 500mm with 12 M30 mounting bolts, requiring a 2m x 2m x 2.2m concrete foundation for secure installation. The pole weighs 420kg and is compatible with antenna mounting brackets ranging from 90mm to 150mm in diameter. It supports a maximum horizontal load of 300N at the top and incorporates a top-mounted 1.2m lightning rod with a 4Ω grounding resistance, complying with ITU-T K.20 telecommunication safety standards.
This 5G communication octagonal pole is designed for a wide range of telecommunication infrastructure deployment scenarios. It is primarily used in urban dense areas such as downtown business districts, high-rise residential communities, and shopping malls, where its high height and multiple mounting brackets support 5G micro base stations that deliver high-speed, low-latency connectivity. In suburban and rural areas, it is deployed along highways, railway lines, and remote villages to expand 5G coverage, bridging the digital divide and enabling smart agriculture, telemedicine, and remote education. For industrial applications, it is installed in manufacturing plants, logistics hubs, and mining sites to support private 5G networks that enable real-time equipment monitoring and automated operations. Additionally, it is used in coastal areas, mountainous regions, and disaster-prone zones to provide reliable communication infrastructure that remains operational during extreme weather events. Its modular design allows for quick deployment, reducing the time required to launch new 5G services.
