Large Size Heavy-Duty Industrial Bearing

Basic Info

The FAG 6320 is a large-size,heavy-duty deep groove ball bearing featuring a robust machined brass cage and case-hardened steel.It is engineered for high load-carrying capacity and shock resistance in low-to-medium speed industrial applications.

Key attributes

Origin

China

Brand

FAG

Bearing Type

Deep Groove Ball Bearing

Bore Diameter

100 mm

Outer Diameter

215 mm

Width

47 mm

Seal Type

Open (Can be fitted with custom seals)

Cage Material

Brass (Machined)

Ring Ball Material

Case Hardened Bearing Steel (e.g., SAE 8620)

Dynamic Load Rating

124 kN

Static Load Rating

80.0 kN

Limiting Speed

4,300 r/min

Customer reviews

Robert Kim · Acoustic Engineering Manager

The low-vibration bearings supplied for our document scanner feed rollers have effectively resolved inconsistent paper feeding issues. Compared to previous solutions, the mechanical noise measured during operation decreased by 5 dB(A), significantly improving the user experience in quiet office environments. The product consistency across batches is also excellent.

Elena Rossi · Mechanical Design Lead

We integrated your bearings into the tilt mechanism of our monitor arms. Their smooth operation under intermittent, low-speed conditions has eliminated the 'sticking' sensation users previously reported. The mechanism now adjusts effortlessly and maintains position reliably, which is critical for ergonomic office furniture.

Lars Weber · Senior Quality Inspection Engineer

In the high-pressure water pump module of our commercial coffee machines, we tested your company's 6001 series sealed bearings. During continuous testing simulating high-frequency use (approximately 100,000 cycles), the bearings demonstrated good sealing performance and operational stability in environments involving hot water and minor coffee residue, without significant noise increase. This contributes to our control over product return rates.

Product Description

Product Features:

Rings are made from case-hardened steel,designed to provide a hard,wear-resistant surface combined with a tough core for durability under demanding conditions.The machined solid brass cage offers high strength and good thermal conductivity.

Large Size Heavy-Duty Industrial Bearing

Product Specifications:

Dimension series is 03(medium-heavy).Ring material is SAE 8620 or similar,case-hardened to a surface hardness of HRC 60-64.The brass cage material is HPb59-1 leaded brass.

Large Size Heavy-Duty Industrial Bearing
