Utilizing an innovative strip-style lamp bar design,this display achieves a light transmittance of 65%-85%,minimizing interference with interior daylighting and outward visibility.Its slim profile,at just 10mm thick,and lightweight construction facilitate straightforward installation.Engineered to deliver high frontal luminance while maintaining notable side transparency,it achieves an optimal equilibrium between vivid imagery and visual permeability.The design supports flexible configurations,enabling creative shapes such as curves and circles.A modular structure simplifies both installation and upkeep.Side-emitting LED lamps ensure a uniform display output.The system supports pixel-level brightness and chrominance calibration,guaranteeing consistent performance across the entire screen.It is designed for harmonious integration with architectural glass curtain walls,preserving the building's aesthetic.Multiple control options are supported,including wireless and network-based systems.
Pixel Pitch:5.0mm
Resolution:40,000 pixels per square meter
Brightness:5,000 cd/m²
Light Transmittance:65%-85%
Thickness:10mm
Weight:12 kg/m²
Power Consumption:Max 400W/m²,Average 150W/m²
Viewing Angle:Horizontal 160°/Vertical 160°
Grayscale:14-bit
Refresh Rate:3840Hz
Protection Rating:IP40
Operating Temperature:-20℃to+50℃
Installation Methods:Suspended/Wall-mounted/Hung
This display is widely applicable in shopping mall windows,brand flagship stores,museums,science centers,exhibition halls,and building curtain walls.For window displays,it can showcase dynamic advertisements while maintaining sightlines to products,effectively engaging customer attention.In building facades,it enables the transformation of standard glass into dynamic media surfaces—appearing as transparent glass by day and a luminous display by night.In stage design,it contributes to distinctive visual effects and can add depth to the performance environment.It is well-suited for high-end retail,brand presentation,artistic installations,and other scenarios that benefit from innovative display solutions.The product can be customized into various forms to accommodate specific design objectives.
