The outdoor P6 display features a fully sealed die-cast aluminum cabinet with a front protection rating of IP65,completely preventing ingress of rain and dust.Its LED lamps use high UV-resistant encapsulation materials,effectively countering color fading caused by direct sunlight.Brightness can reach 6500-8000 nits and is equipped with an ambient light sensor for automatic brightness adjustment(0-100%),saving energy while ensuring clarity during the day and softness at night.The cabinet interior employs efficient thermal conduction and anti-condensation design,ensuring stable operation in extreme temperatures from-30°C to+60°C.It supports remote cluster control,status monitoring(temperature,humidity,voltage),and intelligent fault alarms for convenient maintenance.
Pixel Pitch:P6(6mm)
Brightness:6500-8000 cd/㎡(auto-adjustable)
Pixel Density:27,777 dots/㎡
Viewing Angle:Horizontal 120°/Vertical 120°
Grayscale Levels:14-16 bit
Refresh Rate:≥1920 Hz
Protection Rating:IP65
Operating Temperature:-30°C~+60°C
Operating Humidity:10%~90%RH
Average Power Consumption:Approx.350 W/㎡
Screen Weight:≈55 kg/㎡
Optimal Viewing Distance:6-60 meters
Primarily used for building facade advertising,highway information signs,perimeter scoreboards in sports stadiums,commercial plaza pole advertisements,gas stations,and other fixed outdoor locations.Its high reliability and visibility make it an ideal choice for urban landmark media and long-term brand advertising positions.During sports events,it can broadcast live updates and ads;at transportation hubs,it can display public information and traffic guidance.
Detailed Attribute Values:
Package Type:DIP 546 Tri-color Lamp OR SMD 3535 Black LED
Cabinet Material:Die-cast Aluminum Alloy,surface anti-corrosion spray coating.
Mask Material:UV-resistant PC(Polycarbonate)with diffuser additive.
Sealing Material:Silicone gaskets for waterproofing and dustproofing.
PCB:High TG value FR-4,with conformal coating.
Power Supply:Mean Well/Moso outdoor-rated waterproof power supplies.
Control System:Nova/Linsn high-protection sending cards and receiving cards for outdoor use.
Heat Dissipation Design:Large aluminum fins on the back for natural convection cooling.
Lightning Protection:Built-in primary power surge protector(20KA).
Wind Load Rating:Can withstand wind speeds up to 60m/s.
Signal Transmission:Supports Cat5e+Ethernet cable or fiber optic transmission,anti-interference.
Certifications:CE,FCC,IP65,RoHS,Salt Spray Test≥72H.
