Interactive LED Floor Tile Display

Product Features:

The interactive floor tile utilizes a high-strength die-cast aluminum cabinet with a composite panel of tempered glass or polycarbonate.The surface is specially treated for anti-slip and anti-glare properties to ensure pedestrian safety.Its core feature is the integration of high-precision pressure sensors or infrared sensing modules,capable of accurately capturing actions like stepping or walking and triggering preset animations(e.g.,water ripples,blooming flowers,particle diffusion).The display supports millisecond-level response for real-time interaction.It employs high-brightness SMD LEDs internally,ensuring clear visibility even in well-lit indoor environments.The modular design allows for rapid assembly/disassembly and maintenance.It also features excellent heat dissipation and waterproofing(front IP65),making it suitable for direct use as a stage floor.

Product Specifications:

Pixel Pitch:P3.9,P4.8,P6.25(options available)

Load Capacity:≥1000kg/㎡(static),suitable for crowd walking and equipment transport.

Brightness:1200-1500 nits(adjustable)

Refresh Rate:≥3840Hz

Sensing Type:Infrared Matrix/Pressure(Weight)Sensing

Response Time:<20ms

Protection Rating:Front IP65/Rear IP54

Cabinet Thickness:45-55mm(ultra-slim design)

Optimal Viewing Distance:3-20 meters

Operating Temperature:-10°C~+50°C

Product Applications:

Widely used in digital exhibition halls,brand flagship stores,children's play areas,stage performances,and themed commercial spaces.In exhibitions,it can guide visitor flow and trigger information display via footsteps.On stages,it can become part of the performance,creating light/shadow effects synchronized with dancers'movements.In commercial spaces,it significantly enhances customer engagement and entertainment for games and advertising.Its robust construction also makes it suitable for large auto shows,temporary fashion shows,and other events requiring heavy load-bearing surfaces.
