The product features a double-glass structure that enhances corrosion resistance and impact resistance, with monocrystalline PERC cells delivering high conversion efficiency. Its hidden frame installation design avoids damaging the building's overall facade appearance, while the intelligent temperature-resistant coating reduces solar heat radiation transfer into the building. It supports customized sizes and colors to match different architectural styles, and offers remote real-time power generation monitoring to help building managers optimize energy usage. Compared to traditional single-panel photovoltaic walls, it reduces building cooling load by 12% while generating stable electricity output.
The panel consists of 6mm+6mm ultra-white tempered glass, with monocrystalline PERC cell size of 158.75mm×158.75mm. The frame is made of 6063-T5 aluminum alloy, with a total weight of 28kg per square meter. The operating temperature range is -40℃ to 85℃, with short-circuit current of 9.2A and open-circuit voltage of 38.4V, rated power of 320W per square meter. It supports both on-grid and off-grid power connection, and comes with a 10-year product warranty and 25-year performance warranty.
This product is suitable for high-rise office buildings, commercial complexes, airport terminals and other large public buildings. It is ideal for projects requiring LEED Gold or higher certification, as well as urban landmark buildings that need to showcase green technology. It can be used for new building facade construction and existing building energy-saving renovation projects, providing clean electricity for office equipment, lighting systems and other on-site loads.
