The core advantage of this product is its multi-functional integration, which combines solar power generation, sunshade and thermal insulation, solving the multiple pain points of traditional curtain walls such as high solar heat gain and single function. The adjustable aluminum alloy sun louvers can automatically adjust the angle according to the sun's position, reducing solar heat gain by up to 60% compared with traditional glass curtain walls, significantly reducing the air conditioning load of the building. The thermal break aluminum alloy frame provides excellent thermal insulation performance, reducing the heat transfer between indoor and outdoor, and the 12-level wind resistance rating meets the safety requirements of coastal high-wind areas.
Standard single panel size is 1500mm × 3000mm, panel thickness is 22mm, unit weight is 38kg per square meter. The adjustable sun louvers have an adjustment range of 0° to 90°, and the light transmittance is fixed at 28% to ensure uniform indoor lighting. The product has a sound insulation performance of 38dB, which can effectively block outdoor noise, and the water penetration resistance rating is IP67. The embedded installation method integrates the curtain wall and the building structure, improving the overall stability of the building.
This product is suitable for large office buildings, shopping malls, airports, railway stations and other public buildings with high requirements for sunshade, thermal insulation and fire safety. It can be used as the exterior facade or sunshade system of atriums and exterior windows, providing comprehensive solutions for building energy conservation, fire safety and aesthetic design.
