It adopts double-glass packaging technology, avoiding backboard aging and extending the service life by 10% compared with traditional crystalline silicon modules. The translucent design with 30%-40% light transmittance ensures sufficient natural indoor lighting, solving the pain point that traditional photovoltaic curtain walls have low light transmittance affecting indoor lighting. The ultra-white tempered glass has excellent impact resistance and weather resistance, capable of withstanding extreme weather such as hail and strong winds. The modular design is easy to install, quickly adapting to residential balcony and exterior facade renovation projects, providing long-term electricity cost reduction benefits for residents.
The conventional unit panel size is 1000mm×2000mm, with a glass structure of 6mm+0.76PVB+6mm tempered laminated glass. The photovoltaic module output power is 190-220W per square meter, with a working voltage of DC 28-38V compatible with household photovoltaic grid-connected inverters. The overall system thickness is 100mm, weight 16kg/㎡, wind pressure resistance meets EN 1279 standard, fire rating reaches A1 level, and the sound insulation volume ≥35dB.
It is suitable for residential balcony railings, low-rise villa exterior facades, public rental housing buildings and new rural self-built houses. It can replace traditional glass balcony railings and exterior wall curtain walls as building envelopes, providing clean energy for residences while ensuring indoor lighting needs, reducing household electricity costs, and conforming to the national rural revitalization and green housing policy orientation.
