The wide-temperature design ensures stable operation in the range of-20℃to 60℃,making it suitable for high and low-temperature industrial scenarios.It adopts LVDS high-speed interface,enabling fast data transmission and delay-free image display.The LED backlight offers low power consumption with standby power≤1W,reducing the overall energy consumption of the equipment.The flame-retardant ABS housing and metal bracket provide excellent vibration and impact resistance,adapting to the vibrating environment of production lines.With an ESD resistance rating of 8kV,it can effectively resist electrostatic interference in industrial environments.The 1500:1 contrast ratio ensures clear image display,meeting the requirements of dense industrial data presentation.It supports 7×24 continuous operation with MTBF≥50,000 hours,ensuring high reliability in long-term use.
Display area:697.68×392.26mm;Pixel Pitch:0.518×0.518mm;Response Time:5ms;Viewing Angle:170°(H)/160°(V);Driver IC:ILI9488;Backlight Type:Edge-lit LED,8 lamp beads;Input Voltage:DC12V;Power Consumption:≤45W;Dimensions:720×415×15mm;Weight:3.2kg;Interface:30pin LVDS;Brightness Adjustment Range:200-400cd/㎡;Complies with industrial-grade EMC standards;Passes high and low-temperature cycle tests.
Suitable for CNC machine tool operation panels,it displays processing parameters and program codes to facilitate precise machining.Applied in medical testing equipment such as hematology analyzers and ultrasonic diagnostic instruments,it shows test data and images to assist medical diagnosis.Used in power control cabinets,it displays real-time operating data such as voltage and current to ensure safe power supply.It can also be embedded in automated warehousing equipment,displaying cargo location and inbound/outbound information to improve the efficiency of warehouse management and logistics operations.
