2.4-inch Segment LCD Screen

Basic Info

A low-power consumption segment display module, suitable for electronic scales, remote controls and other equipment. The IIC interface features fewer wires, supports customized segment display patterns, and meets the simple data display needs of small-sized devices.

Key attributes

Origin

China

Size

2.4 inches

Panel Type

TN

Contrast Ratio

300:1

Interfaces

IIC

Backlight Type

LED

Material

0.7mm Glass + PCB

Operating Temperature

-10℃~60℃

Service Life

60,000 hours

Certifications

CE/RoHS

Display Mode

Segment

Power Consumption

≤0.5W

Customer reviews

Maximilian Schmidt · Electronics Engineer

The low-power consumption feature of your 2.4-inch segment LCD screen is amazing, which perfectly meets the needs of our electronic scale products. The TN panel ensures clear display, and the customized segments accurately present weight data. The IIC communication interface has simple wiring, which greatly simplifies the circuit design. The mass supply efficiency is high and the product consistency is strong, effectively reducing our production costs. It is the preferred display component for small household appliances.

Kairos Bowen · Outdoor Field Researcher

My outdoor phone is equipped with this 1500nit high-brightness screen. It delivers clear map viewing and data reading under the scorching midday sun in the desert, with far better visibility than ordinary screens.

Sophia Wang · Product Designer

We embedded your 7-inch embedded LCD dot matrix screens in our smart home control panels. The 800×480 resolution combined with IPS panels delivers delicate images and wide viewing angles. The 4SPI interface features simple wiring and strong adaptability. The backlight design ensures clear display even in dim environments. With low power consumption and a compact size, the modules perfectly meet the lightweight requirements of smart home devices, and the customization service is also very thoughtful.

Product Description

Product Features:

The TN panel has ultra-low power consumption with static current ≤10μA, significantly extending the battery life of battery-powered equipment. The IIC communication interface only requires 2 wires for data transmission, simplifying circuit design and reducing production costs. It supports customized segment patterns such as numbers, symbols and simple graphics, adapting to the display needs of different equipment. The LED backlight offers uniform brightness and supports customized colors such as white and red, matching the appearance design of equipment. The 0.7mm ultra-thin glass substrate reduces the module thickness to only 2.5mm, facilitating embedding into small-sized devices. It passes high and low-temperature cycle tests, ensuring stable operation in the temperature range of -10℃ to 60℃, suitable for both indoor and outdoor environments. With low cost, it is suitable for mass production, helping to control the overall cost of equipment.

Product Specifications:

Display area: 28×36mm; Number of Segments: Customizable (e.g., 8-digit numbers + symbols); Driving Method: 1/4DUTY; Operating Voltage: 2.5-5V; Backlight Type: 2 edge-lit LED lamp beads; Input Current: ≤50mA; Dimensions: 35×45×2.5mm; Weight: 8g; Interface: IIC 2pin; Glass Hardness: 6H; Response Time: ≤20ms; Operating Humidity: 10% - 90%RH; Complies with RoHS environmental protection standards; Passes lead-free certification; Driver IC: HT1621; Supports 3-level brightness adjustment, adapting to different light environments.

Product Applications:

Suitable for electronic scales, it displays weight, unit price and total price with clear and easy-to-read digits, improving measurement efficiency. Used in remote controls, it shows volume, channel and battery level information to enhance user operation convenience. Embedded in small household appliances such as rice cookers and microwave ovens, it displays cooking time and temperature parameters to realize intelligent control of household appliances. It can also be applied in smart water/electricity meters, displaying usage and remaining balance to facilitate user energy management and fee payment.

Frequently Asked Questions (FAQ)

Q：What is the display principle of this segment LCD screen? What content is it suitable for displaying?

A：It adopts TN segment display principle, suitable for displaying numbers, symbols and simple graphics, and is mainly used for parameter display of electronic scales, remote controls and other equipment.

Q：What is the interface type? Is the wiring simple?

A：It adopts IIC communication interface, which can complete data transmission with only 2 wires. The wiring is simple, which greatly simplifies the equipment circuit design.

Q：How about the power consumption? Is it suitable for battery-powered equipment?

A：The static power consumption is ≤10μA, extremely low power consumption, very suitable for small battery-powered equipment, which can significantly extend the battery life.

Q：Can the segment pattern be customized?

A：It supports customizing the segment pattern according to customer needs, and the number of digits and symbol styles can be adjusted to meet the display needs of different equipment.

Q：What is the operating temperature range?

A：The operating temperature range is -10℃~60℃, which can adapt to different indoor and outdoor temperature environments with strong stability.

Q：What is the module thickness? Is it suitable for small equipment?

A：The module thickness is only 2.5mm, with small size and weight of only 8g, very suitable for embedding in small household appliances and smart wearable devices.
