The IPS wide-viewing angle panel offers 178° horizontal and vertical visibility, suitable for multi-angle viewing scenarios. The 0.55mm ultra-thin glass substrate reduces the module thickness to only 3.4mm, facilitating embedding into small-sized equipment. The 4SPI interface features simple wiring, compatible with mainstream controllers such as STM32 and Arduino, reducing development difficulty. The LED backlight has low power consumption with operating current ≤100mA, extending the battery life of equipment. It supports customized backlight colors such as white, blue and green, adapting to different equipment design styles. With high reliability, it passes high and low-temperature and humidity tests, suitable for both home and industrial environments. It displays 262K colors, presenting delicate images to meet the display requirements of small-sized equipment.
Display area: 154.08×85.92mm; Pixel Pitch: 0.1926×0.1926mm; Response Time: 10ms; Driver IC: ST7701S; Backlight Type: Edge-lit 4 LED lamp beads; Input Voltage: DC3.3V; Power Consumption: ≤2W; Dimensions: 163.9×102.7×3.4mm; Weight: 50g; FPC Interface: 0.3mm pitch, 45pin; Supports sleep mode with power consumption reduced to ≤0.1W; Complies with RoHS standards; Glass Hardness: 6H (scratch-resistant); Uniformity: ≥85% (no obvious light leakage in the display area).
Embedded in smart home control panels, it displays parameters such as light brightness and air conditioning temperature to realize intelligent home control. Suitable for small medical instruments such as blood glucose meters and blood pressure monitors, it shows test data to assist health monitoring. Used in vehicle tire pressure monitoring devices, it displays real-time tire pressure and temperature information to ensure driving safety. It can also be applied in smart door locks, displaying unlocking records and battery status to improve the intelligence level of security products.
